Medical PCB Assembly
//Medical PCB Assembly Services
Medical PCB Manufacturing & Assembly
KKPCB is a medical PCB manufacturer based in Shenzhen, China who has extensive years of experience spanning 2 decades in offering world-class medical PCB assembly and manufacturing services. We have the capacity to assemble everything from head to toe of the medical diagnosis and treatment devices, healthcare monitoring devices, advanced therapeutic treatment devices, and other critical medical electronics.
We stay on top of the ever-evolving trends in the medical and dental industry and understand the critical nature of these devices based on which human lives have relied. So, we make sure to incorporate high-precision and error-free boards to achieve the level of sophistication required for these life-saving devices. We provide end-to-end solutions to our clients from the medical industry and save them the time and cost overheads of moving across multiple vendors.
With a brilliant team of IPC-trained personnel, we ensure to strictly comply with the IPC class 3 standards. We also adhere to the RoHS and lead-free PCB assembly requirements of the medical industry.
// MEDICAL PCB ASSEMBLY
Our Medical PCB Assembly Services Includes
Medical Device PCB Design
KKPCB has been one of the leading Medical PCB Assembly companies tirelessly working for the medical devices PCB design. We are adept at designing flex, rigid, and rigid-flex medical printed circuit boards and can build compact PCBs that fit into any compartment of the equipment. We pay great attention to the nitty-gritty of the PCB design to make them damage-resistant and reduce high heat dissipation. We also stay current on the rapid developments in PCB designs of the medical systems and brace up to upgrade the equipment as per the trends and challenges.
Lead-Free Medical PCB Assembly
Compliance is our top priority. No matter what medical application you need PCBs for, we make sure to find lead-free PCBs that comply with RoHS regulations. We provide RoHS-compliant surface finishes and materials for all the products to protect the environment, safeguard the workers’ safety and patient’s health. We also maintain stringent control over all incoming vendor components. We are in constant pursuit of finding and replacing safer alternatives for your PCB. By complying with the RoHS guidelines, we make sure that your company’s bottom line is not affected in any manner.
Rigid-Flex Circuit Board Assembly
In the medical industry, a necessity arises to build ultra-slim circuit boards especially for small devices like pacemakers. We fabricate circuit boards with higher pad and wire density with closer spaces, and finer lines to build the smallest & lightest solutions for your circuit designs. Even if you need rigid-flex materials, we provide optimal solutions to build shock-resistant environments and high-precision medical applications. Through advanced rigid-flex circuit designs, we design circuitry for building versatile and strong boards.
Extensive Material, Substrate, and Coating
We pick the right PCB substrate materials for building a high-quality medical PCB assembly. With so many kinds of substrates, coating, and materials available, we pick the low-cost and highly reliable material for laying a strong foundation for your medical PCB assembly. We selectively coat with parylene for improving the surgical procedures’ lubricity and ensure electrical insulation. The structural integrity of your medical devices will be maintained with a perfect platform or canvas for holding all of the components. The performance and durability of your circuit boards and other components are guaranteed.
Solder Paste Stenciling
We speed up the assembling of your components through solder paste stenciling. When we apply solder paste on your board, we use high-tech machineries like reflow ovens or pick-and-place machines for letting that glue together. We aim for high-precision and repeatable solder paste deposition in the medical PCB assembly. You can have the flexibility to apply solder paste only where you need it. We help you pick the stencil type based on your requirements. We use both manual stencil printers or automated printers for getting your stencil ready. We also polish the stencils and can print multiple boards without losing accuracy.
Reflow Soldering
We aim to form acceptable solder joints through reflow soldering method of attaching the surface mount components on to PCBs. We take all precautions to not damage the PCB or components through overheating. We make sure to pick the suitable machine and acceptable reflow profiles. We then focus on PCB footprint design and carefully use well-designed stencil. By picking the good quality PCB, components, and solder paste, we place your surface mount components in the most reliable and effective manner for both prototype and mass production.
Fine Pitch, BGA & Micro BGA placement
We offer fine pitch, BGA, and micro BGA placements. We have delivered many high-density PCB assembly boards with a significantly high amount of components using fine pitch placement. We tend to push the limits of your PCB fabrication tolerances through fine-pitch components. We also route the BGA and micro-BGA pins with a number of layers and without high-end fabrication techniques and we ensure BGA and micro BGA placement without damaging nearby components. In many wearable devices, we use micro BGA packages.
Medical PCB Prototype for High-Temperature Measurement
We provide a comprehensive range of PCB assembly prototypes that can withstand and remain resilient even in extremely high temperatures. We offer PCB prototypes for three categories – standard temperature, high temperature, and extreme temperature. Both the standard and custom-designed PCB prototypes can be provided for high-temperature circuits. We help you avoid erratic system performance and outright failures in cases of elevated temperatures. You can be assured of maintaining the structural integrity of your devices even when they have to deal with extreme temperatures.
// SELECTING THE BEST MEDICAL DEVICE SOLUTIONS SUPPLIER
Medical PCB Assembly Techniques
KKPCB follows a cost-effective and efficient process for placing and assembling electronic components on the surfaces of medical printed circuit boards accurately and precisely. We have experience with all the three assembly technologies –
- Surface-Mount Technology (SMT)
- Through-Hole Technique (THT)
- Mixed (Both SMT and THT)
However, we recommend Surface Mount Technology to assemble PCBs for medical systems. You can utilize the latest automated equipment for building high-level quality and compact-sized PCBs. We follow the surface mount technology assembly process for building lighter and compact boards and for meeting the unique requirements of the medical systems during the circuit board assembly. Our engineers at KKPCB are capable of creating higher density and increasingly complex circuit boards even in smaller assemblies at envious precision.
Through SMT techniques, we build extremely fast and cost-effective medical PCB assemblies. Through SMT technology, we also reduce the overall assembling time by eliminating the need for drilling holes in the PCB. In addition to SMT PCB assembly, we are also capable of providing conventional through-hole technique. Through-hole mounting is used when we have to manufacture robust medical devices and also during the prototyping stages of the build.
-01
Medical PCB Assembly Capabilities
The following Medical PCB assembly capabilities have made us one of the leading PCB assembly service providers in the USA.
X-ray Machine
We have photon dynamics superior X-ray (SX) series that provides high-resolution and high-magnification X-ray inspection capability in a flexible and compact workstation configuration. It has got a wide selection of X-ray sources, image intensifiers, sample manipulators, and software. Equipped with photon dynamics’ RTI-580 image processing systems, we process real-time X-ray images and provide accurate results for both production and research applications.
IoT Usage
As the advancements take place in PCBs, we also rely on IoT! Data interconnectivity is the need of the hour for improving medical systems. We build smart devices when connected with IoT to provide real-time data about the patients to the medical professionals. This helps them to operate with much greater precision based upon high-precision sensors.
| Capabilities | |
|---|---|
| Types of Medical PCB Assemblies | Rigid, Flex, and Rigid-flex |
| PCB Materials | Standard FR4 Tg 140°C, Tg 170°C, and Tg180°C, Copper Core, and Aluminum core |
| RoHS-compliant | Yes |
| Surface Finish Options | Hot Air Solder Leveling, Lead-Free HASL, Immersion Tin, Immersion Silver, Electroless Nickel/Immersion Gold, and many more |
| Advanced PCB Options | Fine Pitch, BGA & Micro BGA placement ESD, moisture, sensitivity, FIFO procedures |
-02
Medical PCB Assembly Testing Capabilities
KKPCB follows nothing but the best practices during the PCB assembly process. We are uniquely equipped to handle any challenges that deteriorate the quality of the systems and also help you bring only reliable medical devices to the market. As it is a known thing that all medical PCBs should comply with strict sanitary and quality standards, we make sure the PCBs or other electronics that need to go into your device systems meet these highest quality benchmarks.
We also perform the assembly and prototype services in small batches as it gives us ample time to perform quality assurance checks at critical moments throughout the medical PCB design and manufacturing process. We perform a final inspection using an X-ray inspection or Automated Optical inspection. Our X-ray inspection station is top-notch and features digital control, an X-Y table, and an image intensifier. Our engineers use this to ensure high-level quality controls for medical applications.
Testing Capabilities
- X-Ray Inspection
- Automated Optical Inspection (AOI)
- Temperature Testing
- Camera Inspection
- Product-specific Functional Testing
- Fly-probe Testing (To validate component Placement)
- In-circuit Testing (To detect parametric or design failures)
- Functional Testing (To control behavior and functions of PCB)
Follow below given process to get medical PCB assembly quote –
- Go to PCB assembly quote page.
- Collect important PCB design files to add in assembly quote page.
- Enter details in quote page and upload your design files.
- Answer security question and hit submit button.
- If you have any query, contact us on sales@kkpcb.com
//MEDICAL DEVICE APPLICATIONS
Multifarious Usage of Medical PCB Assembly
KKPCB offers extensive PCBA, wire harness, cable, and box build assembly services for medical device markets. Our experienced team works with customers to fully realize their medical device designs, regardless of the complexity.
PCB Assembly
PCB assembly are vital components in medical devices, ranging from diagnostic equipment to monitoring systems, surgical tools, and implantable devices. Precise PCB assembly ensures the accurate and reliable functioning of critical electronic systems, enabling precise measurements, data processing, and control mechanisms.
- Diagnostic Equipment
- Monitoring Systems
- Surgical Tools and Instruments
- Implantable Medical Devices
- Patient Monitoring Devices
- Medical Imaging Systems
- Laboratory Equipment
- Therapeutic Devices
- Rehabilitation and Assistive Devices
- Prosthetics and Orthotics
Cable & Wire Harness
- Diagnostic Equipment
- Patient Monitoring Devices
- Surgical Instruments
- Imaging Systems
- Rehabilitation and Assistive Devices
- Therapeutic Devices
- Laboratory Equipment
- Prosthetics and Orthotics
- Dental Instruments and Devices
- Telemedicine Devices
Box build assembly
- Patient Monitoring Systems
- Surgical Equipment Control Units
- Diagnostic Device Enclosures
- Imaging System Consoles
- Laboratory Instrument Enclosures
- Therapeutic Device Housings
- Rehabilitation Equipment Control Panels
- Medical Device Interface Panels
- Telemedicine Device Enclosures
- Dental Equipment Control Units
// FAQ Medical PCB Assembly
Medical PCB Assembly
Frequent Questions
What is a medical PCB?
Medical PCBs are designed specifically for making medical devices and systems. These are built by taking different lab settings and test scenarios into consideration.
Why do we need compact circuit boards in medical systems?
Small and denser printed circuit boards are the need of the hour! There is a great reduction in the component placement density which helps in reducing the error margin. These compact boards also help in heat dissipation and hence the latest medical systems are incorporating compact boards.
How do l choose a PCB assembly company for my medical devices?
With plenty of options available for you, you can go for a certified and experienced CM for building error-free and top-quality PCB assemblies for medical systems. The CM you are choosing should be aware and must be meeting the rigorous medical standards. An experienced contract manufacturing (CM) is an excellent option as it takes away the hassles from taking your products to the market.
Why should l choose KKPCB for medical printed circuit board assembly?
KKPCB has 4 decades of experience in PCB assembly services. We are also an IPC-certified company and take care of all the regulations levied down for the medical PCB assembly systems. We also make sure to keep the turnaround time to the lowest when compared to the other CMs. We also have a strong supply chain that lets us pick only the high-quality equipment to build sophisticated medical devices. You can also rely on our brilliant team for any sort of support.
How do l get started to inquire about medical printed circuit boards?
To help you get started, we furnish some information for DFM checks and you would be able to easily see and download DRC files. You can request a quick PCB assembly service quote from here.
What are the benefits of medical PCB assembly?
With Medical PCBs, the following are made possible
- Data-driven Medicine
- Electronic health records
- Mobile health
- Wearable devices
How do you avoid low-quality or bad components?
We have a reliable supply chain of vendors and distributors who supply only good-quality components for the PCB build. We also employ methods like traceability to avoid the usage of counterfeit components.
How much do you charge for a medical PCB assembly?
KKPCB is a complete turnkey solution provider. We make sure to keep your costs down and honor your broader business goals. We make the process smooth and trouble-free to avoid unnecessary iterations and cost overheads. Let us know your medical circuit board requirements, we will provide you the final quote.
What is your usual turnaround time to assemble medical PCBs?
Well, that entirely depends on the device you want. But we have experience in effectively utilizing the commercial-off-the-shelf components (COTS) that speed up the design process. These COTS that we use are from a reputable source and are meant to improve the efficacy of the medical PCBs.
How do you balance customization and quality of printed circuit boards?
Our engineers follow a meticulous process for balancing both customization and quality and are ever-equipped to meet any unique requirements you have to assemble your circuit boards. We do it in small batches with superior attention to detail. We also automate certain components for high-volume orders.
